Regenerative Burner for Melting Furnaces

VAREGAENVICOM®

The VAREGAEnvicom® Burner has been specifically developed for use in melting furnaces, addressing the unique demands of high-temperature industrial melting processes while fully complying with the most stringent environmental regulations and complies with Best Available Techniques (BAT).
LEARN MORE
Regenerative Burner for Melting Furnaces

Why VAREGAENVICOM® Burner?

Thanks to its regenerative heat recovery system, the VAREGAENVICOM® bruner offers outstanding energy efficiency—reducing operating costs while protecting the environment.

Its well-engineered design ensures low maintenance requirements and an extended service life, making it a long-term investment for melting furnace operations.

While versatile enough for various furnace types, the burner has been specially optimized for melting applications, with a strong focus on minimizing emission—particularly nitrogen oxides (NOx) and carbon monoxide (CO)—actively contributing to cleaner air and a more sustainable production environment.

Low NOx

Specially Optimized for Melting Furnaces

Saving Energy

Key Features

Power:

Single-head up to 8 MW, double-head up to 12MW

Staged combustion & internal recirculation

Cleaning and replacement from outside the furnace

Ceramic balls (quick exchange) or honeycombs (longer intervals)

Roof Mounted (rm) or Flor Mounted on Rails (fm) installation possible

O2-content of the furnace atmosphere

Integration into furnace control with real-time data

Performance Table

VAREGAENVICOM®

Based on measurements and a complete melting cycle of an SVE35 (5MW) furnace.

     Parameter – Value

  • Specific Gas Consumption for melting (per t AI to 720 °C): ≤ 550 kWh/t
  • Specific CO2 footprint: ≤ 110 kgCO2eq/t
  • Emission Values
    • NOx: ≤ 140 ppm | ≤ 290 mg/Nm³
    • CO: ≤ 44 ppm | ≤ 50 mg/Nm³
    • TOC or VOC: ≤ 5 mg/Nm³
Varega Burner

Advantages of the Burner

  • Significant energy savings through hot combustion air (up to 1050 °C)
  • Low emissions thanks to advanced combustion technology
  • Maintenance-friendly due to modular design
  • Flexible combination with various regenerator types
  • Customizable for individual furnace concepts
  • Support through 3D models and technical documentation
Varega Burner

Burner Sizes

Burner Performance & Melting Rate:

  • Single head: 2 MW power | ~ 2.7 t/h melting rate
  • Single head: 4 MW power | ~ 5.5 t/h melting rate
  • Single head: 5 MW power | ~ 6.8 t/h melting rate
  • Single head: 6 MW power | ~ 8.2 t/h melting rate
  • Single head: 8 MW power | ~ 11.0 t/h melting rate
  • Double head: 10 MW power | ~ 13.7 t/h melting rate
  • Double head: 12 MW power | ~ 16.4 t/h melting rate
